CW – Shaft Loading Cable Winding Machines

Autoreel’s CW series of cable winding machines comprises rugged, heavy duty units designed to facilitate the handling of electrical cable, wire rope, flexible hose and many other reel-stored materials.

CW – Shaft Loading Cable Winding Machines

These are invaluable machines for fast, efficient and accurate rewinding and measurement of master reels and of metering and conversion into part reels, short lengths and coils. They are ideal any establishment concerned with the distribution manufacture, installation, storage or conversion of cable and similar reeled materials, the range can provide substantial benefits for fast, efficient and accurate rewinding and measurement of master reels and of metering conversion into part reels, short lengths and coils. Collapsible coiling heads are easily exchanged for the drum shaft enabling the CW range to be adopted to coiling.

STANDARD FEATURES

Powered by an infinitely variable speed motor
Mounted on steerable wheels
Spring actuated foot brakes
Main shaft with collets to suit various drum bores
Short shaft to suit plywood and cardboard drums
Manual cable layering device.
Drum mounting attachments to suit all popular drum sizes.
Manual double acting hydraulic hand pump connected to displacement rams on CW1000, CW2000, electrically operated pump on CW4000 and CW6000
Various drum driving attachmemts
Dead man control switch

OPTIONAL EXTRAS AVAILABLE

A variety of linear measuring meters.
Collapsible coiling heads.
Electrical motor driven manoeuvring carriage.
Additional safety guards.
Cable cutting attachments – Disc Cutter, Hydraulic shears etc.
Automatic Layering.
Electro hydraulic lifting pump to raise/lower the drum – standard on CW4000, CW6000.

CW range Autoreel's CW series of cable winding machines comprises rugged, heavy duty units designed to facilitate the handling of electrical cable, wire rope, flexible hose and many other reel-stored materials.

Technical Information

Please review the information below for specific technical information.

  • CW 1000
  • Max Drum Diameter
    1500mm
  • Max Drum Width
    1100mm
  • Max Drum Weight
    1000Kg
  • Machine Depth
    1800mm
  • Machine Height
    10500mm
  • Machine Width
    2300mm
  • CW 2000
  • Max Drum Diameter
    1800mm
  • Max Drum Width
    1150mm
  • Max Drum Weight
    2000Kg
  • Machine Depth
    1900mm
  • Machine Height
    1130mm
  • Machine Width
    2450mm
  • CW 4000
  • Max Drum Diameter
    2200mm
  • Max Drum Width
    1275mm
  • Max Drum Weight
    4000Kg
  • Machine Depth
    2150mm
  • Machine Height
    1300mm
  • Machine Width
    2550mm
  • CW 6000
  • Max Drum Diameter
    2400mm
  • Max Drum Width
    1400mm
  • Max Drum Weight
    6000Kg
  • Machine Depth
    2750mm
  • Machine Height
    1550mm
  • Machine Width
    2850mm
